4 Leg/2 Leg Chain Sling

Name: 4 Leg/2 Leg Chain Sling
Brand: Baoding Huaxin Crane Machinery Co., Ltd.

Grade 80 Rigging Hardware Chain Slings, crafted from high - quality materials with great wear resistance, are ideal for diverse lifting tasks in crane, hoist, binding, and industrial operations.

Specifications of 4 Leg/2 Leg Chain Sling

Angle and specifications	Single limb(t)	Two limbs(t)		Three limbs(t)		Four limbs(t)
	Single limb(t)	Two limbs(t)		Three limbs(t)		Four limbs(t)
	0°	0-45	>45-60°	0-45°	>45-60°	0-45	>45-60°
	1	1.4	1	2.1	1.5	2.1	1.5
φ6	1	1.4	1	2.1	1.5	2.1	1.5
φ8	1.5	2.1	1.5	3.1	2.2	3.1	2.2
φ10	2.5	3.5	2.5	5.2	3.7	5.2	3.7
φ10	2.5	3.5	2.5	5.2	3.7	5.2	3.7
φ12	3.5	4.9	3.5	7.3	5.2	7.3	5.2
φ14	5	7	5	10.5	7.5	10.5	7.5
φ16	6	8.4	6	12.6	9	12.6	9
φ18	8	11.2	8	16.8	12	16.8	12
φ20	10	14	10	21	15	21	15
φ22	12	16.8	12	25.2	18	25.2	18
φ24	14	19.6	14	29.4	21	29.4	21
φ26	17	23.8	17	35.7	25.5	35.7	25.5
φ30	22	30.8	22	46.2	33	46.2	33
φ34	29	40.6	29	60.9	43.5	60.9	43.5
